Figure 2. CRA back panel.
P/N TAB14228700A
8
7
6
5
J
V9
V7
BR
G
G
VS
VS
VM
C1
C3
HS
R3
L3
NL
DHR
OC
TB1
Ratio
Correction
Transformer
(RCT)
TB8
C Knife Switch
V1 Knife Switch
V6 Knife Switch
TB2
RCT
Terminal
Board
3CL-7 control replacement assembly installation instructions and service information MN225017EN October 2016
