Figure 11. Back side of QD5 tap-changer.
#7 Stationary
#6 Stationary
#5 Stationary
#3 Stationary
#2 Stationary
#1 Main
Stationary
Contact
VL-Reversing
Stationary
Contact
Neutral
Stationary
VR-Reversing
Stationary
Contact
#8 Stationary
#4 Stationary
Reversing
Neutral
Stationary
Contact
6
QD5 QUIK-DRIVE TAP-CHANGER INSTALLATION AND MAINTENANCE INSTRUCTIONS MN225012EN March 2016
