Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
654 Duration of
Last Level2
0 Cycles
01/01/1970 12:00:00a
Cycles View NA Operate NA NA NA
•A display with date and time stamped of the duration in cycles of the last recorded Level
2 fault since last reset.
•On a multi-phase the right arrow is used to scroll to the display for each phase.
654 Duration of
Longest Level2
0 Cycles
01/01/1970 12:00:00a
Cycles View NA Operate NA NA NA
•A display with date and time stamped of the duration of the longest recorded Level 2
fault since last reset.
•On a multi-phase the right arrow is used to scroll to the display for each phase.
655 Fault Detect
Level3 Threshold
400 Amps
Amps View Modify NA 400 5 16000
•This setting defines the current level which must be exceeded for a Level 3 Fault to be
recorded by the control.
•On a multi-phase the right arrow is used to scroll to the setting for each phase.
656 Fault Detect
Level3 Recovery
399 Amps
Amps View Modify NA 399 4 16000
•This setting defines the level below which current must fall for a Level 3 Fault Recovery
to be recorded.
•On a multi-phase the right arrow is used to scroll to the setting for each phase.
657 Fault Level3
Threshold Timer
1000 mSec
mSec View Modify NA 1000 20 30000
•This setting defines the minimum time duration over which the Level 3 Fault Detect
Threshold Current must occur for a fault to be recorded.
•On a multi-phase the right arrow is used to scroll to the setting for each phase.
658 Fault Level3
Recovery Timer
1000 mSec
mSec View Modify NA 1000 20 30000
•This setting defines the minimum time duration over which the Level 3 Fault Detect
Recovery Current must occur for a fault recovery to be recorded.
•On a multi-phase the right arrow is used to scroll to the setting for each phase.
659 Duration of
Last Level3
0 Cycles
01/01/1970 12:00:00a
Cycles View NA Operate NA NA NA
•A display with date and time stamped of the duration in cycles of the last recorded Level
3 fault since last reset.
•On a multi-phase the right arrow is used to scroll to the display for each phase.
99
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
