Eaton 600 A 15 kV class push-OP User Manual

Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
752 Source Voltage
Secondary (L-N)
----- Volts
Volts View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Source Voltage Secondary from
Line to Neutral.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
753 Source Voltage
Secondary (L-L)
----- Volts
Volts View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Source Voltage Secondary from
Line to Line.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
754 Load Voltage
Primary (L-N)
----- kVolts
kVolts View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Load Voltage Primary from Line
to Neutral.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
755 Load Voltage
Primary (L-L)
----- kVolts
kVolts View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Load Voltage Primary from Line
to Line.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
756 Source Voltage
Primary (L-N)
----- kVolts
kVolts View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Source Voltage primary from Line
to Neutral.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
757 Source Voltage
Primary (L-L)
----- kVolts
kVolts View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Source Voltage Primary from Line
to Line.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
760 Load Voltage
Angle (L-N)
----- Degrees
Degrees View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Load Voltage Angle from Line to
Neutral.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
101
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
