Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
920 Firmware Version
X.X.X
--- View NA NA NA NA NA
•A display of the firmware version currently active on the control.
921 Firmware
Database Version
X
--- View NA NA NA NA NA
•A display of the firmware Database version currently installed on the control.
922 FPGA Version
X.X.X
--- View NA NA NA NA NA
•A display of the FPGA version currently installed on the control.
923 Digital Hardware
Revision
X
--- View NA NA NA NA NA
•A display of the Digital Hardware Revision of the control.
924 BootUtility
Version
X.X.X
--- View NA NA NA NA NA
•A display of the BootUtility version currently installed on the control.
925 BootLoader
Version
X.X.X
--- View NA NA NA NA NA
•A display of the BootLoader version currently installed on the control.
941 Language
Selection
English
--- View Modify NA English NA NA
•This setting allows the user to select the language to display. Options include: English;
Spanish; French; Portuguese.
942 Date Format
MM-DD-YYYY
--- View Modify NA MM-DD-YYYY NA NA
•This setting allows the user to select how the date format will be displayed.
•Options include: MM-DD-YYYY; DD-MM-YYYY; YYYY-MM-DD.
943 Time Format
12 Hour AM/PM
--- View Modify NA
12 Hour
AM/PM
NA NA
•This setting allows the user to select whether time will be displayed on the 12-hour or
the 24-hour scale. Options include: 12 Hour AM/PM; 24 Hour.
944 Key Mapping
Selection
Cl-7 Advanced
--- View Modify NA
CL-7
Advanced
NA NA
•This setting allows for the selection of one of the preprogrammed keypad mapping
configurations or to select the custom user option. The options are: CL-7 Advanced; CL-7
Basic; Standard Platform; Custom User.
•To program the Custom User option, ProView NXG Software must be used.
950 USB Memory Drive
Save All Data
--- View View NA NA NA NA
•This is a command to write control data to a USB memory device. Refer to Section 7:
Advanced Control Features: USB memory device.
950 USB Memory Drive
Save Custom All
--- View View NA NA NA NA
•This command saves all settings from a control onto a USB memory device. Using the
custom option will include the control ID in the file name as a default.
117
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
