Table9. Function menu (continued)
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Sub-Menu
Level 4
Sub-Menu Parameter
Function
Code
*METERING (Cont.) *Instantaneous (Cont.) Total kW Load 133
Total kvar Load 133
Motor Voltage 139
Load Voltage Secondary (L-N) 750
Load Voltage Secondary (L-L) 751
Source Voltage Secondary (L-N) 752
Source Voltage Secondary (L-L) 753
Load Voltage Primary (L-N) 754
Load Voltage Primary (L-L) 755
Source Voltage Primary (L-N) 756
Source Voltage Primary (L-L) 757
Load Voltage Angle (L-N) 760
Load Voltage Angle (L-L) 761
Source Voltage Angle (L-N) 762
Source Voltage Angle (L-L) 763
*Forward Demand Forward Load Voltage High 020
Forward Load Voltage Low 020
Forward Load Voltage Present 020
Fwd Compensated Voltage High 021
Fwd Compensated Voltage Low 021
Fwd Compensated Voltage Present 021
Forward Load Current High 022
Forward Load Current Low 022
Forward Load Current Present 022
Power Factor at Max Forward kVA 023
Power Factor at Min Forward kVA 023
Forward kVA Load High 024
Forward kVA Load Low 024
Forward kVA Load Present 024
Forward kW Load High 025
Forward kW Load Low 025
Forward kW Load Present 025
Forward kvar Load High 026
Forward kvar Load Low 026
Forward kvar Load Present 026
Fwd Load Current Real High 134
Fwd Load Current Real Low 134
Fwd Load Current Real Present 134
Fwd Load Current Reactive High 134
Fwd Load Current Reactive Low 134
Fwd Load Current Reactive Present 134
39
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
