Table9. Function menu (continued)
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Sub-Menu
Level 4
Sub-Menu Parameter
Function
Code
*COMMUNICATIONS
(Cont.)
*Comm Port #1 (Cont.) *IEC 60870-5-104 IEC104 Server Listen Port 813
IEC104 Common Address 813
IEC104 Single Command Op Mode 813
IEC104 Select Before Exec Time 813
IEC104 Response Timeout (t1) 813
IEC104 Ack/No Data (t2) 813
IEC104 Idle Test (t3) 813
IEC104 Max Transmit (k) 813
IEC104 Max Receive (w) 813
IEC104 User Map Selection 813
*2179 2179 Master Address 815
2179 Ignore Master Address 815
2179 Device Address 815
2179 SBO Select Timeout 815
2179 User Map Selection 815
2179 Dead Sync Timeout 815
2179 Master Time Format 815
_Modbus Modbus Device Address 816
Modbus User Map Selection 816
Modbus Listening Port Number 816
*Comm Port #2 *Comm Port #2 Configuration Protocol / Port Type 830
LoopShare Communications 830
ProView NXG Session 830
ProView NXG Address 830
*Serial Configuration Serial Baud Rate 831
Serial Parity 831
Serial CTS Support 831
Serial Tx Enable Delay 831
Serial Tx Disable Delay 831
Serial Echo Mode 831
*Network Configuration IP Address 832
Subnet Mask 832
Gateway 832
MAC Address 832
*DNP3 Basic DNP RBE Master 840
DNP IED Slave 840
DNP IED Slave 2 840
DNP User Map Selection 840
*DNP3 Network DNP Network Protocol Type 841
DNP Accept From Any IP 841
DNP Accept From IP Address 841
DNP Destination Port Number 841
42
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
