Table9. Function menu (continued)
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Sub-Menu
Level 4
Sub-Menu Parameter
Function
Code
*COMMUNICATIONS
(Cont.)
*TCP/IP Re-init TCP IP Socket Re-Init 803
TCP IP Socket Re-Init Timeout 803
*LoopShare LoopShare Comms State 860
LoopShare Comm Table Assignment 861
LoopShare Comm Tx Delay 862
LoopShare Comm Timeout 863
*I/O Control *Aux Module 1 Activate Contact Output 1 089
Activate Contact Output 2 089
Activate Contact Output 3 089
Activate Contact Output 4 089
_Aux Module 2 Activate Contact Output 1 089
Activate Contact Output 2 089
Activate Contact Output 3 089
Activate Contact Output 4 089
_I/O Status *Contact Inputs *Aux Module 1 (Contact status by point) 090
_Aux Module 2 (Contact status by point) 090
_Contact Outputs *Aux Module 1 (Contact status by point) 090
_Aux Module 2 (Contact status by point) 090
44
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
