Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
034 Reverse
kVA Load Low
XXXX.X kVA
MM-DD-YYYY HH:MM:SS
kVA View NA Operate Reset* NA NA
•This is the lowest value of the load kVA during reverse power flow since last reset, as a
demand value, according to the demand time interval at FC 46.
•Date and time of the occurrence the lowest kVA load is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
034 Reverse
kVA Load Present
XXXX.X kVA
kVA View NA NA NA NA NA
•This is the present value of the load kVA during reverse power flow, as a demand value,
according to the demand time interval at FC 46.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
035 Reverse
kW Load High
XXXX.X kW
MM-DD-YYYY HH:MM:SS
kW View NA Operate Reset* NA NA
•This is the highest value of the load kW during reverse power flow since last reset, as a
demand value, according to the demand time interval at FC 46.
•Date and time of the occurrence of the highest kW load is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
035 Reverse
kW Load Low
XXXX kW
MM-DD-YYYY HH:MM:SS
kW View NA Operate Reset* NA NA
•This is the lowest value of the load kW during reverse power flow since last reset, as a
demand value, according to the demand time interval at FC 46.
•Date and time of the occurrence of the lowest kW load is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
035 Reverse
kW Load Present
XXXX.X kW
kW View NA NA NA NA NA
•This is the present value of the load kW during reverse power flow, as a demand value,
according to the demand time interval at FC 46.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
58
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
