Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
465 Reverse
Set Voltage
XXX.X Volts
Volts View Modify NA 120.0 100.0 135.0
•Reverse Set Voltage for Alternate Configuration 1.
466 Reverse
Bandwidth
X.X Volts
Volts View Modify NA 2.0 1.0 6.0
•Reverse Bandwidth for Alternate Configuration 1.
467 Reverse
Time Delay
XXX Seconds
Seconds View Modify NA 45 5 180
•Reverse Time Delay for Alternate Configuration 1.
468 Rev Line Drop
Comp. Resistance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Reverse Line Drop Compensation Resistance for Alternate Configuration 1.
469 Rev Line Drop
Comp. Reactance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Reverse Line Drop Compensation Reactance for Alternate Configuration 1.
470 Control
Operating Mode
Sequential
--- View Modify NA Sequential NA NA
•The Control Operating Mode for Alternate Configuration 1.
471 Reverse Sensing
Mode
Locked Forward
--- View Modify NA
Locked
Forward
NA NA
•The Reverse Sensing Mode for Alternate Configuration 1.
472 Reverse Current
Sense Threshold
X %
% View Modify NA 1 1 5
•The Reverse Current Sense Threshold for Alternate Configuration 1.
473 Auto Operation
Blocking Status
Normal
--- View Modify NA Normal NA NA
•The Auto Operation Blocking Status for Alternate Configuration 1.
474 Voltage
Reduction Mode
Off
--- View Modify NA Off NA NA
•The Voltage Reduction Mode for Alternate Configuration 1.
475 Local/Digital
Reduction Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Local/Digital Reduction Value for Alternate Configuration 1.
476 Remote #1 Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote latch #1 Voltage Reduction Value for Alternate Configuration 1.
87
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
