HMi Series Instruction Leaflet
MODEL HMI04BU HMI04CU HMI06BE HMI06GE
Power
Consumption
(Note 5)
2.64W 3.36W 7.2W 7.2W
Voltage Endurance
AC500V for 1 minute
(between charging (DC24 terminal) and FG terminals)
Operation Temp. 32°F ~ 122°F (0°C ~ 50°C)
Storage Temp. -4°F ~ 140°F (-20°C ~ +60°C)
Ambient Humidity
10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
Pollution Degree 2
Shock 30G @ 11ms
Vibration Resistance
IEC 61131-2 Compliant
5Hz f≦ ＜9Hz = Continuous: 1.75mm / Occasional: 3.5mm
9Hz f 150Hz = Continuous: 0.5g / Occasional: 1.0g≦≦
X, Y, Z directions for 10 times
Backup Battery 3V lithium battery CR2032 x 1 / Battery life: 5 years
Backup Battery Life
It depends on the temperature used and the conditions of usage, about
3 years or more at 25oC.
Buzzer Multi-Tone Frequency (2K ~ 4K Hz) / 85dB
Dimensions
(W) x (H) x (D) in Inches
(mm)
5.54 x 4.13 x 1.76
(140.8 x 104.8 x 44.8)
7.25 x 5.67 x 1.85
(184.1 x 144.1 x 47)
Panel Cutout
(W) x (H) in Inches (mm)
4.68 x 3.65
(118.8 x 92.8)
6.79 x 5.21
(172.4 x 132.4)
Weight in Lbs. (kg) .69 (.315) .62 (.310) 1.69 (.768)
NIT Rating 100 cd/m
2
300 cd/m
2
130 cd/m
2
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum
driving current is supplied to HMi. The life of LED backlight shown is an estimated value under 25
o
C
normal temperature and humidity conditions.
2) Program memory is used for recipes.
3) USB Host port can provide up to 5V/ 500mA of power.
4) Please use isolated power supply (not applicable for HMI08CE and HMI10CE).
5) The value of the power consumption indicates the electrical power consumed by HMi only without
connecting to any peripheral devices. In order to ensure the normal operation, it is recommended to
use a power supply which the capacity is 1.5 ~2 times the value of the power consumption.
6) For further details, please visit the Eaton website www.eaton.com/electrical.
