Before You Begin i-on30EX/EXD
Page 6
1. Built-in communicator telephone
line connector. (i-on30EXD only.)
2. Siren and strobe.
3. Loudspeaker.
4. Bus cable connector.
5. Output (transistorised).
6. Aux power.
7. Wired zone connectors.
Figure
3
Control Unit Main Connectors
