Eaton MDS-C20 User Manual

I.B. 2C12060H08
For more information visit: www.EatonElectrical.com
Instruction Book
Page 14
Effective: May 2006
OPEN
PUSH OFF
DISCHARGED
PUSH ON
CLOSED
CHARGED
Figure 3-5 Typical Magnum DS/DSX Drawout Circuit Breaker Front Cover
Trip Flag (Pop Out Indicator)
Three Accessory Windows
Trip Unit
Rating Plug
Contact Status (Open-Close)
Spring Status (Charged-Discharged)
2
1
4
3
6
2
1
8
7
10
3
9
11
12
Manual “OFF” Button (Push)
Manual “ON” Button (Push)
Manual Charge Handle
Optional Operation Counter
Padlockable Levering Device Access
Door for Drawout Breaker
5
8
7
Color Coded-Breaker
Position Indicator
Nameplate
Trip Unit Test Port
Trip Unit Cover with Two
Mounting Screws (Mounting
Screws will Accept Customer
Supplied Lead Security Meter
Seals
10
9
11
(Red)
(Green)
(Yellow)
(White)
(Green)
(Red)
5
13
14
12
13
CONNECT
TEST
DISCONNECT
CONNECT
TEST
DISCONNECT
4
14
15
6
15
Red = Connect
Yellow = Test
Green = Disconnect
