Eaton Power Xpert PXR Series User Manual

34
10 Available protection settings
PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com
The PXR trip unit style codes are shown in the table:
Trip unit
style
Trip unit model and
protection function
Communication, relay, maintenance mode, zone interlock
(options)
B1N PXR10 LI
B2N PXR10 LSI
E2N PXR20 LSI
E2R PXR20 LSI Relays
E2Z PXR20 LSI ZSI and relays
E2M PXR20 LSI Modbus and relays
E2C PXR20 LSI CAM and relays
E2W PXR20 LSI ZSI and Modbus (and relays)
E2X PXR20 LSI ZSI and CAM (and relays)
E3R PXR20 LSIG Relays
E3Z PXR20 LSIG ZSI and relays
E3M PXR20 LSIG Modbus and relays
E3C PXR20 LSIG CAM and relays
E3W PXR20 LSIG ZSI and Modbus (and relays)
E3X PXR20 LSIG ZSI and CAM (and relays)
E4R PXR20 LSI ARMS Relays
E4Z PXR20 LSI ARMS ZSI and relays
E4M PXR20 LSI ARMS Modbus and relays
E4C PXR20 LSI ARMS CAM and relays
E4W PXR20 LSI ARMS ZSI and Modbus (and relays)
E4X PXR20 LSI ARMS ZSI and CAM (and relays)
E5R PXR20 LSIG ARMS Relays
E5Z PXR20 LSIG ARMS ZSI and relays
E5M PXR20 LSIG ARMS Modbus and relays
E5C PXR20 LSIG ARMS CAM and relays
E5W PXR20 LSIG ARMS ZSI and Modbus (and relays)
E5X PXR20 LSIG ARMS ZSI and CAM (and relays)
D2M PXR20D LSI Modbus and relays
D2D PXR20D LSI Modbus and CAM (and relays)
D2W PXR20D LSI ZSI and Modbus (and relays)
D2Y PXR20D LSI ZSI, Modbus, and CAM (and relays)
D3M PXR20D LSIG Modbus and relays
D3D PXR20D LSIG Modbus and CAM (and relays)
D3W PXR20D LSIG ZSI and Modbus (and relays)
D3Y PXR20D LSIG ZSI, Modbus, and CAM (and relays)
D4M PXR20D LSI ARMS Modbus and relays
D4D PXR20D LSI ARMS Modbus and CAM (and relays)
D4W PXR20D LSI ARMS ZSI and Modbus (and Relays)
D4Y PXR20D LSI ARMS ZSI, Modbus, and CAM (and relays)
D5M PXR20D LSIG ARMS Modbus and relays
D5D PXR20D LSIG ARMS Modbus and CAM (and relays)
D5W PXR20D LSIG ARMS ZSI and Modbus (and relays)
D5Y PXR20D LSIG ARMS ZSI, Modbus, and CAM (and relays)
P2M PXR25 LSI Modbus and relays
P2D PXR25 LSI Modbus and CAM (and relays)
P2W PXR25 LSI ZSI and Modbus (and relays)
P2Y PXR25 LSI ZSI, Modbus, and CAM (and relays)
P3M PXR25 LSIG Modbus and relays
P3D PXR25 LSIG Modbus and CAM (and relays)
P3W PXR25 LSIG ZSI and Modbus (and relays)
