Eaton Power Xpert PXR Series User Manual

46
10 Available protection settings
PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com
10.2.25 PDC4 PXR10 settings (LI)
Frame 800 A 1000 A All 800 A 1000 A
Profile Long delay Instantaneous
Dial Ir (A) Ii (x In)
Setting Pickup Ir (amps)
Time (s)
at 6x (Ir) Pickup li = nx (In)
A
320 400 10 2 2
B
350 550 10 3 3
C
400 630 10 4 4
D
450 700 10 5 5
E
500 750 10 6 6
F
550 800 10 6.5 6.5
G
600 850 10 7 7
H
630 900 10 7.5 7.5
J
700 950 10 8 8
K
800 1000 10 8.5 8
Instantaneous override
6800 A 8000 A
10.2.26 PDC4 PXR10 settings (LSI)
Frame 800 A 1000 A All All 800 A 1000 A
Profile Long delay Short delay Instantaneous
Dial Ir (A) SD profile Ii (x In)
Setting Pickup Ir (amps)
Time (s)
at 6x (Ir)
Pickup (Isd)
Isd =nx (lr)
Time (tsd)
tsd (s) Pickup li = nx (In)
A
320 400 10 2.0 0.150 2 2
B
350 550 10 2.0 0.300 3 3
C
400 630 10 2.0 I
2
t 4 4
D
450 700 10 4.0 0.150 5 5
E
500 750 10 4.0 I
2
t 6 6
F
550 800 10 6.0 0.150 6.5 6.5
G
600 850 10 6.0 0.300 7 7
H
630 900 10 10.0 0.150 7.5 7.5
J
700 950 10 2.0-8.0 0.05 to 0.30 8 8
K
800 1000 10 OFF - 8.5 8
Configurable using PXPM software Instantaneous override
6800 A 8000 A
