Eaton Power Xpert PXR Series User Manual

56
11 Modbus register map
PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com
Set points group 0: system group
Register
Bit
field
Mask
field
Set point
name R/W Format Value definition Unit DEC HEX
403000 BB7 15-0 Password W "0-0-0-0" (factory default)
403001 BB8 15-0 0xFFFF Group 0 =
system
R/W 0x00FF (hex) 255 (dec)
403002 BB9 12-0 0x1FFF Rating
information
R Encoded PD2
PD3A: 125, 250, 400.
PD3B: 400, 600, 630.
PD4: 800, 1000.
PD5:
PD6:
A
403003 BBA 2-0 0x0007 Breaker frame R Encoded 00 --> NRX NF
01 --> NRX RF
11 --> NZM2
12 --> NZM3
13 --> NZM4
21 --> PD2
22 --> PD3
23 --> PD3H
24 --> PD4
25 --> PD5
26 --> PD6
403004 BBB Style1 R Encoded
0 = false
1 = true
b0 --> LdSel : with long delay protection
b1 --> SdSel : with short delay protection
b2 --> InstSel : with Inst protection
b3 --> GfSel : with ground fault protection
b4 --> ARMSel : with maintenance mode
b5 --> OvrideSel : with override protection
b6 --> RCDSel : with ground fault RCD
b7 --> MotorSel : with motor protection
b8 --> NeuSenorSel : with neutral sensor
b9 --> ThermalSel : with thermal memory
b12 --> VoltSel : with voltage sampling feature
b13 --> ExtADCSel : with external AD7779
403005 BBC 3-0 0x000F Style2 R Encoded
0 = false
1 = true
b0 --> ModbusSel : with integrated Modbus
b1 --> CAMSel : with CAM RS422 port
b2 --> IOModuleSel : with IO module port
b3 --> RelaySel : with relay
b4 --> ZSISel : with ZSI
b12 --> NZM_ACB_Sel
b13 --> IECSel : IEC = 1, UL = 0
403006 BBD 8 0x0100 Maintenance
mode: state
R Encoded 0 = Off 1 = On
BBE 0x0001 Maintenance
mode: remote
control
R/W Encoded 0 = Off 1 = On
403007 BBE 2-0 0x0007 Arms level R/W Encoded 1 = 2.5 * In
2 = 4 * In
3 = 6 * In
4 = 8 * In
5 = 10 * In
A
403008 BCF Frequency R Unsigned Range: 50, 60 , 400 Hz
403009 BC0 0 0x0001 Rev feed R/W Encoded 0 = Forward 1 = Reverse
403010 BC1 0 0x0001 Sign convention R/W Encoded sign convention :
0 = IEC, 1 = IEEE, 2 = IEEEalt
403011 BC2 Power window R/W Encoded Power demand window :
0 = fixed, 1 = sliding
403012 BC3 Power interval R/W Encoded Power demand interval:
[5…60] min
min
