C. The pinion cam is pointing to the right over the
holding switch actuator. See Figure52.
Figure 52. Neutral position for position indicator pinion
cam and holding switch.
Pinion Cam
Holding Switch
Actuator
22
QD5 QUIK-DRIVE TAP-CHANGER INSTALLATION AND MAINTENANCE INSTRUCTIONS MN225012EN March 2016
