Requirements for Reverse Sensing Mode without IDPTs
039 Source Voltage Calculation Function, 39, Enter, Edit Scroll - On; Off, Enter
Required for Reverse Sensing Modes
051 Reverse Set Voltage Function, 51, Enter, Edit, Value, Enter
052 Reverse Bandwidth Function, 52, Enter, Edit, Value, Enter
053 Reverse Time Delay Function, 53, Enter, Edit, Value, Enter
054 Reverse Line Drop Comp. Resistance Function, 54, Enter, Edit, Value, Enter
055 Reverse Line Drop Comp. Reactance Function, 55, Enter, Edit, Value, Enter
056 Reverse Sensing Mode Function, 56, Enter, Edit, Scroll - Locked Forward; Locked Reverse; Reverse Idle;
Bi-directional; Neutral Idle; Co-generation; React Bi-directional, Enter
Required for Voltage Reduction Mode
070 Voltage Reduction Mode Function, 70, Enter, Edit, Scroll - Off; Local/Digital Remote; Remote/Latch; Remote/
Pulse, Enter
072 Local/Digital Reduction Value Function, 72, Enter, Edit, Value, Enter
073 Remote #1 Value Function, 73, Enter, Edit, Value, Enter
074 Remote #2 Value Function, 74, Enter, Edit, Value, Enter
075 Remote #3 Value Function, 75, Enter, Edit, Value, Enter
076 # of Pulse Reduction Steps Function, 76, Enter, Edit, Value, Enter
077 % of Voltage Red Per Pulse Step Function, 77, Enter, Edit, Value, Enter
Required for Voltage Limit Mode
080 Voltage Limit Mode Function, 80, Enter, Edit, Scroll - Off; High Limit Only; High/Low Limits, Enter
081 High Voltage Limit Function, 81 Enter, Edit, Value, Enter
082 Low Voltage Limit Function, 82, Enter, Edit, Value, Enter
Table 3-1. Programming for Basic Operations
Function
Code Description Instructions
99 Security Function Function, 99, Enter Password 32123 (default), Enter
1 Forward Set Voltage Function, 1, Enter, Edit, Value, Enter
2 Forward Bandwidth Function, 2, Enter, Edit, Value, Enter
3 Forward Time Delay Function, 3, Enter, Edit, Value, Enter
4 Forward Line Drop Comp. Resistance Function, 4, Enter, Edit, Value, Enter
5 Forward Line Drop Comp. Reactance Function, 5, Enter, Edit, Value, Enter
40 Regulator Identification Function, 40, Enter, Edit, I. D. number, Enter
41 Regulator Configuration Function, 41, Enter, Edit, Scroll - Wye; Delta Lagging; Delta Leading, Enter
42 Control Operating Mode Function, 42, Enter, Edit, Scroll - Sequential; Time Integrating; Voltage Averaging, Enter
43 System Line Voltage Function, 43, Enter, Edit, Value, Enter
44 Overall P.T. Ratio Function, 44, Enter, Edit, Value, Enter
45 C.T. Primary Rating Function, 45, Enter, Edit, Value, Enter
46 Demand Time Interval Function, 46, Enter, Edit, Value, Enter
49 Tap Changer Type Function, 49, Enter, Edit, Scroll - Cooper QD8; Cooper QD5; Cooper QD3; Cooper Spring Drive;
Cooper Direct Drive; Siemens; General Electric; Howard; LTC-Reinhausen, Enter
50 Calendar/Clock Function, 50, Enter, Edit, Month, Day, Year, Hour, Minute, Enter
140 Regulator Type Function, 140, Enter, Edit, Scroll - Type A; Type B; Type C; Type D, Enter
144 P.I. ADD-AMP™ High Limit Function, 144, Enter, Edit, Value, Enter
145 P.I. ADD-AMP Low Limit Function, 145, Enter, Edit, Value, Enter
146 Vin P.T. Configuration Function, 146, Enter, Edit, Scroll - Vdiff Mode; Vin Mode, Enter
69 Auto Operation Blocking Status Function, 69, Enter, Edit, Scroll - Normal; Blocked, Enter
19
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
