TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
303 Diagnostics Maintenance 303 PMT Mode A
Issue Test
NA 2 NA NA NA NA
• The user can force the PMT Mode A operation independent of the time-delay setting.
• This is a command. When the Enter key is pressed, the (CONFIRM) message is displayed on the fourth line of the LCD.
When the Enter key is pressed again, the test sequence begins.
320 Diagnostics Maintenance 320 PMT Mode B
State
Off
NA 2 NA Off NA NA
• The Preventive Maintenance Tapping (PMT) feature Mode B will automatically raise and lower the tap-changer to wipe
reversing contact blades. The PMT feature Mode B is turned off or on here. The options include:
• Off • On
321 Diagnostics Maintenance 321 PMT Mode B
Countdown Delay
XX Days
0 NA NA NA NA NA
• This is the time remaining until the next PMT Mode B operation.
322 Diagnostics Maintenance 322 PMT Mode B
Time Delay
7 Days
0 2 NA 7 1 99
• This is the user-defined period of time between PMT Mode B operations.
323 Diagnostics Maintenance 323 PMT Mode B
Start Time
22:00
0 2 NA 22:00 00:00 23:59
• When the PMT feature Mode B is turned on (FC 320), operation is enabled only within a specified time period. The starting time is set
here.
324 Diagnostics Maintenance 324 PMT Mode B
Stop Time
02:00
0 2 NA 02:00 00:00 23:59
• The PMT Mode B operation is disabled after the stopping time set here.
325 Diagnostics Maintenance 325 PMT Mode B
Max Deviation
8
0 2 NA 8 1 16
• This is the maximum number of tap positions beyond neutral for which PMT Mode B is enabled.
326 Diagnostics Maintenance 326 PMT Mode B
Designation
Off
0 2 NA Off NA NA
• This allows the performance of PMT Mode B maintenance operations to be coordinated among multiple regulators. Options
include:
• Off • Master • Slave
327 Diagnostics Maintenance 327 PMT Mode B
Current Limit
50 %
0 2 NA 50 0 160
• The PMT Mode B is enabled at or below the current limit setting, defined as a percentage of the CT primary.
TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
328 Diagnostics Maintenance 328 PMT Mode B
Issue Test
NA 2 NA NA NA NA
• This is a command. When the Enter key is pressed, the (CONFIRM) message is displayed on the fourth line of the LCD.
When the Enter key is pressed again, the test sequence begins.
333 Diagnostics Maintenance 333 Contact Duty
Cycle Monitor
XX.XXX%
0 NA NA NA NA NA
• The contact life Duty Cycle Monitor function represents the amount of life consumed, for the worst-case contact, displayed as
a percentage of total life. Individual contact wear levels can be interrogated via the CCI software.
350 Features Compact
Flash
350 CompactFlash
Data Writer
NA NA NA NA NA NA
• This is a command to write information to the compact flash card. Refer to the Advanced Features: Compact Flash Card
section of this manual.
351 Features Compact
Flash
351 CompactFlash
Load Custom Cfg
NA 2 NA NA NA NA
• This is a command to load a custom configuration to the CL-6 control. Refer to the Advanced Features: Compact Flash Card
section of this manual.
352 Features Compact
Flash
352 CompactFlash
Load Std Config
NA 2 NA NA NA NA
• This is a command to load a standard configuration to the CL-6 control. Refer to the Advanced Features: Compact Flash
Card section of this manual.
353 Features Compact
Flash
353 CompactFlash
Save Custom Cfg
NA NA NA NA NA NA
• This is a command to save a custom configuration from the CL-6 control. Refer to the Advanced Features: Compact Flash
Card section of this manual.
354 Features Compact
Flash
354 CompactFlash
Save Std Config
NA NA NA NA NA NA
• This is a command to save a standard configuration from the CL-6 control. Refer to the Advanced Features: Compact Flash
Card section of this manual.
355 Features Compact
Flash
355 CompactFlash
Format CF Card
NA NA NA NA NA NA
• This is a command to format the compact flash card. Refer to the Advanced Features: Compact Flash Card section of this
manual.
357 Features Compact
Flash
357 CF Load Custom
Basic Config
NA 2 NA NA NA NA
• This is a command to load a custom Basic Configuration.
• See Flash Card Functions in the Advanced Control Features section of this manual for more information.
358 Features Compact
Flash
358 CF Load
Standard Basic
Config
NA 2 NA NA NA NA
• This is a command to load a Standard Basic Configuration.
• See Flash Card Functions in the Advanced Control Features section of this manual for more information.
67
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
