Alarm Indicators
Communications
Indicators,
Coms Tx and Rx
LEDs
Control Function
Switch:
Auto/
Remote-Off-Manual
Supervisory On/Off
Switch
Drag-Hand
Reset Switch
Motor
Fuse
Voltmeter
Terminals
External Source
Terminals with
Ground
Manual Raise/Lower
Switch
Power Switch:
Internal,
Off,External
Redundant Neutral-
Indicating Light
(LED)
Multi-Use Keypad:
Numeric Keys,
Function Keys,
Short-Cut Keys
Flash Card Port
and LED
Status Indicators
4 X 20 Character
Liquid Crystal
Display
DB9-Style RS-232 Port
Figure 1-1. Control panel layout.
2
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
