Figure 16. 120/240 VAC 3-wire center-tapped PT control power input (shown with default factory wiring connected to
B-phase voltage metering with B-phase incoming supply)
21OPERATION INSTRUCTIONS MN280049EN September 2017
Form 4D Microprocessor-based pole-mount recloser control installation and operation instructions
