Part No. SW0178 Rev. C 05/07
CAZ2500
STEREO POWER AMPLIFIER
Eastern Acoustic Works | One Main Street | Whitinsville, MA 01588 USA | TEL toll free within US/Canada 888.337.7404
TEL outside US 425.892.6503 | FAX 425.485.1152 | Page 2 of 4
PERFORMANCE
Inputs (balanced)
Sensitivity 1.15 V (+3.4 dBu)
Impedance 20k ohm
Maximum Input Level 9.75 V rms (+22 dBu)
Output
(Continuous sine wave average output power per channel with both channels driven)
575 watts per channel into 8 ohms, 20 Hz to 20 kHz
750 watts per channel into 4 ohms, 20 Hz to 20 kHz
1400 watts per channel into 2 ohms, 20 Hz to 20
kHz
(Bridged Mono operation)
1500 watts into 8 ohms, 20 Hz to 20 kHz
2500 watts into 4 ohms, 20 Hz to 20 kHz
Note: Power ratings are specified at 120 VAC line voltage.
Power Bandwidth
Main In to Amp Out 5 Hz to 50 kHz (+0, –3 dB)
Frequency Response
Main In to Amp Out 25 Hz to 25 kHz (+0, –1 dB)
Noise
Main In to Amp Out >100 dB (below rated power into 4 ohms)
Distortion (THD, SMPTE IMD)
<0.03% @ 8 ohms
Channel Separation
>90 dB @ 1 kHz
Damping Factor
>300 @ 1 kHz and below
Voltage Gain
34 dB (50.1 V/V)
Turn On Delay
2.5 seconds
Subsonic Filter
–9 dB @ 30 Hz, switchable
Protection Circuitry
DC offset
Over-temperature
Short circuit
Current limit
Topology
Class H
Cooling
Dual variable-speed fans with back to front airflow
Indicators
Channels A and B
SIG (Signal Present), OL (Overload)
POWER
Current Consumption
Idle 1.0 A
Musical Program @ 8Ω 8.1 A
Musical Program @ 4Ω 10.0 A
Musical Program @ 2Ω 17.2 A
AC Power Requirements
U.S. 120 VAC, 60 Hz
Europe 240 VAC, 50 Hz
Korea 220 VAC, 60 Hz
Physical
Height 3.5 in/89 mm
Width 19.0 in/483 mm
Depth 15.7 in/400 mm
Weight 56.2 lb/25.5 kg
