SPECIFICATIONS DC6
DIMENSIONAL DRAWING
INPUT PANEL
One Main Street, Whitinsville, MA 01588 508 234 6158 Toll Free 800 992 5013 FAX 508 234 8251 info@eaw.com www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. DC6/2 pp October 2001 Printed in USA
INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (PI ANGLE).
INDICATES MOUNTING POINT
3/8-16 THREADED HOLE (NUT PLATE).
INDICATES CENTER OF BALANCE
5.59
13.35
10.62
30.00
GRILL PARTIALLY SHOWN
FRONT
6.63
INPUT
BACK
1.91
3.63
5.38
3.00
TOP
A
A
DIMENSIONS APPLY
VI
LEFT SIDE
2.28
4.34
6.28
5.62
9.53
3.90
C
L
6.00
1.63
VIEW A-A
9.53
26.07
510893 (0)
8/24/99
ANGLED TOP VIEW (A-A )
Manufacturing tolerances are +/- 0.13 and +/- 1°
10.7
NEUTRIK
NL 4 MPR
NEUTRIK NEUTRIK
NL 4 MPR
NEUTRIK
DC6
WHITINSVILLE, MA USA
S/N
PIN 1--...--
PIN 1+...+
