EAW DX1208 Help File

To edit a Crossover filter from the EQ graph:
1.
<CLICK> the diagonal white Frequency Handle to select the Crossover. The previously
selected Filter’s curve disappears, and the Selected Crossover’s curve appears in yellow
with a solid yellow Frequency Handle.
2.
<DRAG> the Frequency Handle left/right to adjust the Frequency.
Limiter
Description
Each of the eight DX1208 Output Channels is equipped with a Limiter that occurs between the
Output Fader and the Delay in the DX1208 signal chain. The Output Channel Limiter is in all
respects identical to the Input Channel Compressor (see the Input Channel Compressor
section of this helpfile), with two small differences. First, the Limiter uses a hard-knee transfer
curve, while the Compressor uses a soft-knee transfer curve. Second, the Limiter allows an
[Infinite:1] Ratio, while the Compressor is limited to a maximum Ratio of [20:1].
39
