CE DECLARATION OF CONFORMITY
PRODUCT
Product Model: KF730 p/n 0006108
Description: Loudspeaker
Dimensions (h x w x d): 330 mm x 724 mm x 446 mm / 13.0 in x 28.5 in x 17.54 in
Material: 19 ply-per inch Baltic birch plywood
Integral aluminum rigging fittings
Supplied Accessories: 6x Connecting Pin p/n 0006122
OR Button Head Connecting Pin p/n 0020558
Accessories: KF730/SB730 Fly-Bar p/n 0006265
Spare Connecting Pin p/n 0006122
KF730 Caster Pallet p/n 0006385
COUNTRY OF ORIGIN FOR THE PRODUCT AND COMPONENTS
United States of America
TECHNICAL SPECIFICATIONS
The KF730 loudspeaker is to be suspended below or stacked on top of the KF730 Fly-Bar.
When used in accordance with the KF730 Owner’s Manual the Working Load Limits (WLL) and Design
Factor are:
Nominal Weight 34.9 kg / 77 lb
WLL (for enclosure corner rigging points) 680.4 kg / 1500 lb
Ultimate Strength Design Factor >10:1
STANDARDS CONFORMITY
The KF730 loudspeakers are designed and intended to be suspended only from the KF730 Fly-Bar in
accordance with the KF730 / SB730 Loudspeaker Owner’s Manual.
Up to eighteen (18) KF730 loudspeakers may be vertically suspended in a column below the KF730 Fly-Bar.
The maximum recommended quantity of stacked KF730s is six (6).
Combinations of KF730s and SB730s may be flown in the same array. Because KF730s and SB730s have
different weights, the total weight of any combination must not exceed the WLL of the integral rigging
components or that of the KF730 Fly-Bar. For combinations of KF730 and SB730, use these formulas to
determine maximum quantities of each. In all cases, round the answer DOWN to the nearest integer. This
keeps the total weight of the KF730/SB730 combination within the above-specified WLL.
Maximum total quantities for suspended configurations using a combination of KF730 and SB730
loudspeakers are:
Product Maximum Total Combination
KF730 Maximum quantity KF730 = 18 - (quantity SB730 x 1.5)
SB730 Max quantity SB730 = 12 - (quantity KF730/1.5)
The maximum recommended quantity for a stacked combination of KF730/SB730 is six (6) KF730 over four
(4) SB730.
The ultimate strength for the KF730 integral rigging points was determined utilizing calibrated and certified
destructive pull-tests.
Page 1 of 7 November 2006
Eastern Acoustic Works Tel: 800 992 5013
One Main Street e-mail: info@eaw.com
Whitinsville, Ma 01588 www.eaw.com
