KF730P Specifications group · M
ENCLOSURE
Material Baltic birch plywood
Finish Wear resistant textured black paint
Grille Powder-coated perforated steel
1.59
7.66
12.10
15.19
12°
6.00
RIGHT SIDE
DIMENSIONS APPLY TO BOTH SIDES
NOTES:
1. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (PI ANGLE) .
2. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (STRAPPING).
3. SYMBOL INDICATES CENTER OF BALANCE. 4. WEIGHT APPROX. 78 LB. 5. SHIPPING WEIGHT APPROX. 86 LB.
GRILLE PARTIALLY SHOWN
FRONT
13.03
10.23
7.23
C
L
24.72 28.75
(2.01)
DIMENSIONS APPLY TO
TOP AND BOTTOM
VIEW A-A
8.25
C
L
12.17
1.73
A
ACCESS PANEL
A
PRODUCTION
2X HANDLE
(9.83)
7.69
4.69
C
L
EA STERN A C O USTIC W ORKS
2.42
INPUT
5.00
9.134.00
C
L
BACK
KF730P
