ENCLOSURE
Material Exterior-grade Baltic birch plywood
Finish Wear resistant textured black paint
Grille Powder-coated perforated steel
NOTE: This drawing has been reduced. Do not scale.
SB2001 Specifications group • S
Eastern Acoustic Works • One Main Street • Whitinsville, MA 01588 • tel 800 992 5013 / 508 234 6158 • fax 508 234 8251 • www.eaw.com
March 2010Part Number: RD0508 (D) SB2001 SPECEAW products are continually improved. All speci cations are therefore subject to change without notice.
1
2
34
A
B
C
A
B
C
PRO ENGINEER
THE INFORMATION CONTAINED
HEREIN IS PROPRIETARY AND
CONFIDENTIAL PROPERTY OF
LOUD TECHNOLOGIES, INC.
ALL RIGHTS RESERVED
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
DUAL [MM] DIMENSIONS
FOR REF ONLY
TOLERANCE IN INCHES
LINEAR ± 0.13 in / ± 3.3 mm
ANGLES ± 1°
(X.XX) = REF DIMS
NO TOLERANCE IMPLIED
TSC = THEORETICAL SHARP CORNER
DIMENSIONS ACROSS CENTERLINES
TO BE SYMMETRICAL
REVISION:
DRAWING NUMBER:
THIRD ANGLE PROJECTION
TITLE:
SCALE:
1 1
www.eaw.com
A
A
33.50
[850.9]
22.63
[574.8]
29.61
[752.0]
9.27
[235.6]
25.39
[645.0]
45.00
[1143.0]
6.72
[170.6]
7X 10.93
[277.6]
7X 6.56
[166.6]
9.27
[235.6]
25.39
[645.0]
6.72
[170.6]
1.84
[46.8]
18.82
[478.0]
9.27
[235.6]
25.39
[645.0]
3.93
[99.8]
29.32
[744.8]
2X 4.16
[105.7]
4.16
[105.7]
3.75
[95.3]
20.40
[518.1]
45°
29.61
[752.0]
21.50
[546.0]
10.83
[275.0]
6.57
[166.9]
DATECHANGE NUMBERREV
2/16/10ECOWHT6226B
2033687-CD
B
A
SHEET OF
0.025
DWG CUSTOMER SB2001
[MECHANICAL SPECIFICATION]
NOTES:
1. SYMBOL INDICATES CENTER OF BALANCE.
2. SYMBOL INDICATES PI ANGLE 3/8-16.
3. WEIGHT APPROX. 200 lb [91 kg].
4. SHIPPING WEIGHT APPROX. 232 lb [105.5 kg].
FRONT
TOP
2X RUNNER
ROUTS
BOTTOM
2X RUNNERS
RIGHT SIDE
DIMENSIONS APPLY
TO BOTH SIDES
BACK
7X HANDLE
SB2001
VIEW A-A
INPUT
