EAW SM159zi - Performance Data Graphs; Frequency Response Graphs; Impedance and Beamwidth Plots

Eastern Acoustic Works One Main Street Whitinsville, MA 01588 tel 800 992 5013 / 508 234 6158 fax 508 234 8251 www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. Part Number: RD0306 (A) SM159zi May 2005
SM159zi Specifications group · G
PERFORMANCE DATA
See NOTES GRAPHIC DATA for details
Frequency Response: Processed
Complete = blue
SPL (dB)
Frequency Response: Unprocessed
Single-amp = blue
SPL (dB)
Frequency Response: Digital Signal Processor
Single-amp = blue
dB re 0.775 V
Beamwidth (-6 dB SPL Points)
Horizontal = orange Vertical = black
Degrees
Impedance Magnitude
Single-amp = blue
Ohms
120
110
100
90
80
70
60
100
10
1
400
100
10
1
100 1000 20000
Frequency (Hz)
10 100 1000 20000
Frequency (Hz)
10
0
-10
-20
-30
-40
-50
20
10
0
-10
-20
-30
-40
10 100 1000 20000
Frequency (Hz)
10 100 1000 20000
Frequency (Hz)
10 100 1000 20000
Frequency (Hz)
