KF850zF Specifications group · S
PERFORMANCE DATA See NOTES GRAPHIC DATA Notes for details
Frequency Response: Processed Tri-amplified
LF = green MF = Black HF = orange Complete = blue
SPL (dB)
Frequency Response: Unprocessed
LF = green MF = Black HF = orange
SPL (dB)
Frequency Response: Digital Signal Processor
LF = green MF = Black HF = orange
dB re 0.775 V
Beamwidth (-6 dB SPL Points)
Horizontal = orange Vertical = black
Degrees
Impedance Magnitude
LF = green MF = Black HF = orange
Ohms
120
110
100
90
80
70
60
100
10
1
400
100
10
1
100 1000 20000
Frequency (Hz)
10 100 1000 20000
Frequency (Hz)
120
110
100
90
80
70
60
20
10
0
-10
-20
-30
-40
10 100 1000 20000
Frequency (Hz)
10 100 1000 20000
Frequency (Hz)
10 100 1000 20000
Frequency (Hz)
