EBA 551-06 - Blade Replacement Procedure

- 26 -
EBA 551-06 • EBA 551-06 LT
B
A
C
D
•
Blade and cutting stick replacement
•
• Set mains switch (A) to position "I" .
• Set clamping oil pressure (B) to min. 50
bar.
• Press in blade locking key (C).
• Activate cutting © blade remains in lowest
position.
• Set mains switch to position "0".
Remove the left screw (D), using the
extension.
Pull out blade locking key © blade moves to
the top.
