EBA 551-06 - Page 28

- 28 -
EBA 551-06 • EBA 551-06 LT
A
B
•
Blade and cutting stick replacement
•
Remove remaining two screws (A).
Simultaneously slightly loosen both screws
(B) and remove blade with blade changing
tool.
Weight of blade approx. 5 kg.
Place the blade into the blade carrier and
screw it into place.
