- 33 -
A
B
1.
•
Blade and cutting stick replacement
•
Loosen slightly screws (A) so that the blade
slides onto the cutting stick.
Push in the first screw on the left side and
tighten.
Push the blade and screw (B) as far as
possible to the left or right and then centralize
them. © The blade must rest on the cutting
stick.
