- 11 -
3x
3x
1.
2.
3.
3.
3x
3x
2.
1.
B
A
3x
3x
3x
3x
3x
3x
4.
5.
4.
5.
6.
6.
The machine is delivered ready for operation.
6 strong people are required to
lift the machine from the pallet.
Side tables, left and right, (A) are available
as accessories.
Attach the side tables to the front table so
that the upper surface is level.
(Screws and nuts are in a plastic bag in the
tool set (B).
Reassemble the safety light beam.
For transport through narrow doors:
•
Remove side tables
Danger!
The machine must not be put into operation
without the safety light beam.
•
Installation
•
Assemble the side
tables.
Remove the light beam.
(1. - 3.)
Screw on the side tables
and light beam (4. - 6.).
