Specifications
SEVERE DUTY CENTRIFUGAL SEPARATOR
MODEL # SDS SERIES SEPARATOR
MAX PRESSURE 150 psi
PRESSURE LOSS RANGE 5-12 psi
FLOW RANGE 45-1200 gpm
MAX PARTICLE SIZE 3/8"
MATL OF CON. CARBON STEEL (STAINLESS STEEL OPTIONAL)
*CONSULT FACTORY FOR HIGHER FLOW RATES AND OPERATING PRESSURES
CAUTION: FOR USE WITH A CENTRIFUGAL PUMP ONLY! DO NOT USE WITH A POSITIVE
DISPLACEMENT PUMP.
MODEL A B C D E FLOW
RANGE
INLET/
OUTLET
PURGE
SIZE
WEIGHT
DRY
WEIGHT
WET
0150-B 30 4⅜ 4¾ 1¾ 6 45-70 1 1/2" 1 1/2" 27 40
0200-B 33⅝ 55½ 2⅝ 8⅝ 65-108 2" 1 1/2" 52 98
0250-B 37 5½ 6¼ 2⅝ 8⅝ 98-155 2 1/2" 1 1/2" 60 109
0300-B 42 7 8¼ 3¼ 10¾ 148-290 3" 1 1/2" 101 177
0400-B 88 14½ 10 3 ⅛ 11 275-550 4" 1 1/2" 300 410
0500-B 108 16¼ 12 3 11/16 11 480-880 6" 1 1/2" 415 615
0600-B 108 16¼ 12 3 11/16 11 720-1200 6" 1 1/2" 475 714
ALL DIMENSION (") ALL FLOW IN (USGPM)
