Section 2: System Specifications
2.1 Sy
stem utilities requirements
Inlet connection : 3" steel hose barb
Outlet connection: 2 1/2" steel hose barb
Electric
al: 230va
c/3ph/60
Hz
Full load amps: 33.0 amps
2.2 System components
Pump suction basket – PKG-98
Cast iron housing with flanged inlet and outlet connections. Internal basket is constructed of perforated
stainless steel.
System pump – PCL 2x3x10B-CC+6
Close-coupled, all iron construction, 316 stainless steel shaft sleeve, semi-open impeller.
Motor:
Electrical: 230vac/3ph/60Hz
Horse power: 10 hp
Full load amp @ 230vac: 25.6 amps
Speed:
1760 rpm
Enclosure: TEFC
Pump:
PCL 3x4-10-B-CC+6
Impeller: 10“dia.
Centrifugal Separator - SDS-250-B
Carbon steel construction, designed to remove 98% of particulate from liquid, sized at 74 micron and
larger with a specific gravity of 2.6 or higher.
Maximum particle size: 3/8-inch
Maximum pressure rating: 150 psi
Pressure loss range: 4.5 to 12 psi
Electrical controller – EHOA-3
Disconnect supplied by others. Provide maximum upstream protection per NEC code 430-52 and table
430-152
Enclo
sure: Steel, Nema 12
Transformer: 75va primary/secondary fused
Filter pump starter module: Internal sort circuit / thermal overload.
Filter pump starter module: PKZ2 Internal sort circuit / Thermal overload.
Thermal overload yellow dial set point 230vac: 25.6 (FLA of motor)
Sort circuit red dial set point 230vac: 332.8 (13 times FLA of motor)
Pressure gauge – GRS-60-GA
Range:
0-60
psi
Face
dia:
2"
In
let size: 1/4" NPT
Case material:
Stainless/steel
Wetted parts:
Brass
