M3G150 / 200 Disassembly instructions
Document No.: - • Change: 01 • Release date: 2019-02-12 • (VM-POK) • Page 7/9
ebm-papst Mulfingen GmbH & Co. KG • Bachmühle 2 • 74673 Mulfingen • Germany
Phone +49 7938 81-0 • Fax +49 7938 81-110 • info1@de.ebmpapst.com • www.ebmpapst.com
26. Take out the remaining parts of the ball bearing.
27. Detach the O-ring.
28. Unfasten the four screws.
29. Detach the plastic ring.
30. Unfasten the four screws of the connector.
31. Pull out the plug contact.
