EBN BPC03-B-2930 - 2 Opening the Device; Separate Upper Half and Bottom Half

Chapter 2
2
2.
2. Opening the Device
2.1. Separate upper half and bottom half
1. Loosen and remove the screws fixing the I/O panel by hexagon socket spanner.
2. Loosen and remove the screws fixing the front panel by #1 Phillips screwdriver.
3. Open the device as shown below.
