EC Line EC-1530 User Manual

8
WARNING: setting wrong values in the below sections may cause system to
Malfunction
Advanced setup
CPU Configuration
IDE Configuration Configure CPU
USB Configuration
COM/LPT Configuration
Hardware monitor
Power management
↑↓→←: Move +/-:Value Enter : select F10:Save and Exit
F9 : load Defaults Settings F1:General Help Esc : Exit
Step 4: Select Boot
Boot Configuration
Bootup NumLock State
Display Logo
On
Dislabled
Boot Option Priorities
BOOT OPTION
Hard Drive BBS Priorities
SATA:ST3800….
↑↓→←: Move +/-:Value Enter : select F10:Save and Exit
F9 : load Defaults Settings F1:General Help Esc : Exit
Step 5: Select the menu item Security
Supervision Password:Not installed
User Passwrod :Not Installed
Change Supervisor Password
Change User Password
Clear User Password
Boot Setor Virus Protection Dislabled
Flash Write Protection Enabled
Help Item
Install or
change e
password
