XRGI
®
- INSTALLATION GUIDE VERSION 1.0 2018
5
1
3
2 4
1
2
3
4
1
With the CE marking, products comply with the essential requirements of the relevant directives in accordance with the rating plate.
Q-HEAT DISTRIBUTOR
The rating plate is located on the inside of the Q-Heat Distributor
below the electronics box.
Legend
1 Q-Heat Distributor serial no.
2 Type description of the Q-Heat Distributor
3 Technical data of the Q-Heat Distributor
4 CE marking
iQ-CONTROL PANEL
The iQ-Control Panel has two rating plates. These are located on the inside
of the iQ-Control Panel door and on the left side of the iQ-Control Panel,
below the main switch disconnector.
Legend
1 iQ-Control Panel serial no.
2 Technical data of the iQ-Control Panel
3 Type description of the iQ-Control Panel
4 XRGI®-ID of the XRGI® system
1.7 CE MARKING
1.6 VALIDITY OF THE GUIDE
This XRGI® installation guide only applies to XRGI® systems with the following article numbers:
■
Without additional accessories
■
With additional storage tank
Type Article number
XRGI® 6 X060001 / X060002
XRGI® 9 X090001 / X090002
XRGI® 15 X150001 / X150002
XRGI® 20 X200001 / X200002
Fig. 1.02 – Q--Heat Distributor rating plate
Fig. 1.04 – Rating plate iQ-Control Panel
Fig. 1.03 – iQ-Control Panel rating plate
