Emergency Mode Flash Pattern Selection
There are seven customizable emergency flash pattern modes available based on the wire combinations shown in TABLE 3. When using
individual switches, make sure to configure all possible switch combinations. The default setting is unsynchronized which allows each light
head module group to be configured separately and the lightbar to flash in an unsynchronized pattern. Steps to synchronize the light head
module groups together are detailed in later sections.
Level Mode Combinations
Function Wire Color Flash Pattern Modes
GRN/BLK L1
WHT/BLK L2
GRN/BLK & WHT/BLK L1 + L2
RED/BLK L3
GRN/BLK & RED/BLK L1 + L3
WHT/BLK & RED/BLK L2 + L3
GRN/BLK, WHT/BLK & RED/BLK L1 + L2 + L3
TABLE 3
The module groups in each mode come with the default flash patterns shown in TABLE 4.
TABLE 4
Level Mode Default Flash Patterns by Group - Unsynchronized
Light Head
Module Group L1 L2 L3
Front Outboard Off Quad 75 FPM Cycle Flash
Front Inboard Off Quad 75 FPM Cycle Flash
Front Center Off Quad 75 FPM Cycle Flash
Front Corner Off Quad 75 FPM Cycle Flash
Rear Outboard Quad 75 FPM Off Cycle Flash
Rear Inboard Quad 75 FPM Off Cycle Flash
Rear Center Quad 75 FPM Off Cycle Flash
Rear Corner Quad 75 FPM Off Cycle Flash
Rear End Quad 75 FPM Off Cycle Flash
L1 + L2 L1 + L3 L2 + L3 L1 + L2 + L3
Front Outboard Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Front Inboard Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Front Center Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Front Corner Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Rear Outboard Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Rear Inboard Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Rear Center Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Rear Corner Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
Rear End Quad 75 FPM Cycle Flash Cycle Flash Cycle Flash
To change a light head group flash pattern selection:
1. Power-up the Lightbar and apply +power to the level mode wire you wish to change (see TABLE 3). The light bar will flash the default
pattern shown in TABLE 4.
2. Twist together the BLK/RED Pattern select wire in the 16 conductor cable and the wire of the light head group you want to change shown
in TABLE 5.
3. Momentarily touch the BLK/RED and group wire from step 2 to power to cycle through the patterns in TABLE 6. The pattern
for the set of light heads configured will only be set in the level mode selected.
