Orifice diam. Designation Part number Designation Part number Designation Part number Air consumption
mm l/min at 4 bar
0.8 0–7 6001 0241 00 170 6101 2588 00 215
270 6101 2589 00 285
271 6101 5249 00 380
007 6001 0548 00 273 6103 3159 00 370
P007 6101 5747 00 275 6101 2590 00 380
T272 6101 2599 00 480
T278 6101 5614 00 480
T272 6101 2599 00 480
T272
f
6102 3992 00 480
T278 6101 5614 00 480
T278
f
6102 3991 00 480
1.2 170 6101 2588 00 215
271 6101 5249 00 380
273 6103 3159 00 370
T272 6101 2599 00 480
T272
f
6102 3992 00 480
T274 6101 2602 00 480
PT274 6101 5785 00 480
T278 6101 5614 00 480
T278
f
6102 3991 00 480
270 6101 2589 00 285
271 6101 5249 00 380
273 6103 3159 00 370
T272 6101 2599 00 480
M270 6101 3293 00 155
270 6101 2589 00 285
2–7 6000 9140 00 271 6101 5249 00 380
1.8 P2–7 6001 1478 00 P1807
e
6101 3844 00 273 6103 3159 00 370
H2–7 6001 0768 00 275 6101 2590 00 380
T274 6101 2602 00 480
PT274 6101 5785 00 480
3–7 6000 9141 00 M370 6101 3294 00 265
2.1 P3–7 6001 1479 00 P2107
e
6003 9366 00 375 6101 2591 00 385
H3–7 6000 9876 00 T374 6101 2603 00 510
M470 6101 3295 00 305
2.7 475 6101 2592 00 385
T474 6101 2604 00 510
57 6000 9289 00 M570 6101 3296 00 500
P57 6101 6056 00 T576 6101 2607 00 540
6.5 6–7 6001 0451 00 67 6001 0453 00 T676 6101 2608 00 585
1.1 09–7 6001 1068 00 P1107
e
6101 5616
0.8 B0–7 6001 0966 00
1–7 6001 0276 00
P1–7 6001 1476 00
Nozzle sets
Consists of air cap, paint nozzle of stainless steel and paint needle of nylon.
Pressure feed Suction and Gravity feed
Paint nozzle Paint needle Air cap Nozzle set Paint nozzle Paint needle Air cap Nozzle set
Orifice diam. Orifice diam.
mm Type Type Part number mm Type Type Type Part number
1.1 09–7 P007 T278 6003 9772 11 1.1 09–7 P007 271 6003 9771 11
1.3 1.5–7 P07 T272 6003 9772 13 1.3 1.5–7 P07 273 6003 9771 13
1.5 1.5 P07 T272 6003 9772 15 1.5 1.5 P07 273 6003 9771 15
1.8 2–7 P07 T272 6003 9772 18 1.8 2–7 P07 271 6003 9771 18
2.1 3–7 P07 T374 6003 9772 21 2.1 3–7 P07 375 6003 9771 21
2.7 4–7 P07 T474 6003 9772 27 2.7 4–7 P07 475 6003 9771 27
a
The letter “H“ before the designation denotes tungsten-carbide design.
b
The letter “P“ before the designation denotes nylon design. The rear part of the nylon needle is made of steel.
c
Air caps for round spray with “M“ in the designation should be used together with stop ring 6101 3298.
d
Air caps with a “T“ in the designation are designed for pressure feed only. The other air caps are designed for suction feed but can also be used for pressure feed.
e
Fluid needle with cylindrical point.
f
Acetal plastic retaining ring.
3.7 5–7 6000 9287 00
1.5–7 6001 0999 00
1.3 P1.5–7 6001 1477 00 P1307
e
6101 5982 00
H1.5–7 6001 1092 00
Nozzle combinations
Paint nozzle Paint needle Air cap
(a) (b) (a) (b) (b) (c) (d)
07 6000 9275 00
1.5 1.5 6103 1303 00 P07 6001 1471 00
H07 6000 9881 00
4–7 6000 9142 00
H4–7 6000 9877 00
4
