Ecco 40S - Page 7

7
65130 F301
Ecco 40S
Fig. 2
2. Packing set
3. Packing screws
4. Fan with control
12. Paint needle
14. Back head
15. Spring
16. Wheel (Paint flow adjusting)
17. Trigger
21. Air valve
28. Guide pin
29. Packing screw
30. Distributor ring (Air distrubutor)
32. Paint nozzle
33. Air cap
34. Paint hose connection nipple (G 3/8)
42. Air hose connection nipple (G1/4)
47. Strainer (optional equipment)
33 32 12 30 47 28 29 2 3
65130 F225
Fig. 1
Ecco 40
ECCO FINISHING AB
NACKA - SWEDEN
Made in Sweden
16
4
3
34
G 1/4
2-6 bar
42
G 3/8
0.8-2 bar
16 15 14
42 17
21 4
34
