PRIMEMiniDashCamUserManual
Basic Operation Procedure
1) Preparingforvideorecording
• IfyouconnectthepowersupplyandturnonthepowerbuttonwiththeSDcardinserted
inthemainbody,theLEDisturnedonandVoiceannouncementiscomeout.

2) Normalrecording
• AllimagesduringdrivingarerecordedintheunitofminuteandsavedinSDcard.
• IftheSDcardcapacityisexceededduringuninterruptiblerecording,thedevicestartsto
overwritetheexistingfilesstartingwiththeoldest.
• MakesuretowaituntiltheLEDiscompletelyoffbeforeremovingtheSDcardfromtheproduct.

3) Eventrecording
• IfashockisdetectedduringUninterruptiblerecording,theimageisstoredseparatelyin
theEVENTfolder.

(Impactsensitivityisconfigurableinthemobileapp.)
• Thestoragetimeisatleast1minuteto3minutesbefore/afterimpactdetection.
• Duringshockdetectionrecording,eventsoundisgenerated

4) Parkingrecording(onlywhenuninterruptiblepowerisconnected)
• Whenswitchingtotheparkingmode,avoiceannouncementsaying“Parkingmodeisset”
isissued.
• Iftheaccelerationsensordetectsvibration,impact,ormotion,thesetframeisstored
separatelyinthePARKINGfolder
• Toprotectthevehiclebattery,ithasabatterydischargepreventionfunctionthat
automaticallyterminatesrecordingwhenthevoltagedropsbelowthespecifiedvoltage
andreducesbatterydischargebyturningoffthepower.

(Dischargepreventionsettingsareavailableinthemobileapp.)
LED functions
No. Description On O󽗈 Blinking
1 Wi-Fi Wi-Fi dongle connected Wi-Fi dongle not connected
Mobile app
connected
2 SD card 1 SD card 1 connected SD card 1 not connected Malfunction
3 SD card 2 SD card 2 connected SD card 2 not connected Malfunction
4 Front camera
Front camera 1 con
-
nected
Front camera not con-
nected
5 Rear camera Rear camera 2 connected Rear camera not connected
N/A Main - - In operation
Button functions
No. Function Operation Status
Switch A
Voice Recording
On/O󽗈
Press the button 1 time
SD Card Format
Press and hold the button until hearing the beeping
sounds 10 times.
Switch B
Event Recording Press the button 1 time
Factory Reset
Press and hold the button until hearing the beeping
sounds 10 times.
• Eventrecordingfunction:Ifyoupresstheeventbutton,thedrivercansavethedesiredimage
intheeventfolder.
