INSTALLING THE MICROWAVE OVEN
Parts and accessories
Remove all the supplied material from the packaging and from the inside of the oven.
The oven comes with the following accessories:
Glass tray 1
Assembled support 1
Operating manual 1
A) Control panel
B) Tray’s pivot
C) Assembled support
D) Glass tray
E) Window of the oven
F) Door system
G) Door safety lock system
1) Cooking power
2) Low
3) Defrosting / med. low
4) Medium
5) Med. high
6) High
7) Timer
8) Defrosting by weight
Installation in the work space
Remove all the packaging and accessories. Check the appliance for damage, e.g. dents or damaged door. Do not install damaged oven.
Cabinet: Remove all the protective foil from the surfaces. Do not remove the light brown magnetron cover inside the oven.
Installation
1. Select horizontal surface, where will be enough space for operating
and ventilating the oven.
The microwave oven should kept at least 7.5 cm away from
surrounding objects. One side has to be open.
1) Leave at least 30 cm of space above the oven.
2) Do not remove the feet from the bottom of the oven.
3) Blocking the air vents may damage the oven.
4) Place the appliance as far as possible from a TV set or radios.
Operation of the microwave oven may cause interference to
your radio or TV set.
2. Plug the appliance in a standard electrical outlet. Make sure that the voltage and the frequency of the power supply agree with the
data on the label of the appliance.
WARNING: Do not install the oven on a stove surface, or over it or over any other heat source. Should the appliance be damaged by an
external heat source, the warranty would be void.
Open space
30 cm
7.5 cm
7.5 cm
F
G
A
CBED
1
4
5
6
8
2
7
3
