9. Tighten screws with hex key.Step 8. Place the four screws (No.5)

into rail and hand tighten.

Tighten screws with hex

key.

Align the right foot carriage

with the screw holes on the body

of the rower and hand tighten the

three screws (No.8).

ANGLE AWAY

FROM ROW

ASSEMBLY

Step 7. Place the rail onto rail

bracket.

Step

Step 10. Align front foot with screw

holes on the rail and hand tighten

screws (No.8) into the foot.

Step 11. Step 12.
