13
Step 6. Place all four screws (No.7)
into screw holes and tighten with
hex key.
ASSEMBLY
Step 3. Tighten the screws with hex
key.
*Arrow pointing towards side with handle.
Step 1. Remove the bracket(No.14)
and bolt with hex key.
Step 4. Set rower upright and
adjust the arm with screen mount
to your desired level.
Step 5. Place seat on ground and lay
the rail onto seat so the screw holes
on the bracket align with screw
holes on seat.
Step 2. Place the front foot and hand
tighten screws(No.6) into place.
To Next Page
