USER MANUAL
SPRING REVERB &
DSP REVERB/CHORUS
4
REVERB CHORUSSPRING BLEND DIGITAL
IMPORTANT
Use Echo Fix supplied EF-5L tape loops only.
The use of any other tape loop could cause
damage to your EF-X2 and will void your warranty.
The tape type is very important. Clean heads
regularly with isopropyl alcohol and cotton tips.
X Y
PAGE 9 OF 12
The switch marked (X) selects between spring reverb, digital reverb/chorus or
a fixed blend of spring reverb and digital reverb/chorus eects.
The switch marked (Y) selects between digital reverb and digital chorus eect.
(X) Spring + (Y) Reverb = Spring Reverb
(X) Blend + (Y) Reverb = Spring Reverb and Digital Reverb blend
(X) Digital + (Y) Reverb = Digital Reverb
(X) Spring + (Y) Chorus = Spring Reverb
(X) Blend + (Y) Chorus = Spring Reverb and Digital Chorus blend
(X) Digital + (Y) Chorus = Digital Chorus
When (X) is set to “Spring”, the eect is Spring Reverb only and the Reverb
Decay control (O) has no eect.
To have control over the digital reverb decay time or chorus intensity, (X) must
be set to either “Blend” or “Digital”.
