We have designed the EF-X2 to accommodate CV or expression
pedal control of the tape speed and feedback functions. The
control voltage range is 0 - 5v for CV control. The expression
pedal needs to be a TRS output and is recommended to be
100KΩ impedance.
Both the echo and reverb (spring reverb, DSP reverb/chorus)
eects can be disabled via a dual TRS latching footswitch.
PAGE 8 OF 12
4
3
2
1
7
6
5
FEEDBACKTREBLEBASS
ECHO VOLUMESPEEDREVERB VOLUMEREVERB DECAYLINE VOLUMEGUITAR/HI-Z VOLUME
ECHO MODE
CV REMOTE SPEEDLINEGUITAR/HI-Z CV REMOTE FEEDBACK REMOTE EFFECT CANCEL OUTPUT OUTPUT LEVEL
HIGH
LOW
ON
OFF
S. ON S.
ON
OFF
ECHO
ON
OFF
MOTOR
ON
OFF
DIRECT
ON
OFF
SPEED
CONTROL
FEEDBACK
CONTROL
2 CHANNEL
FOOTSWITCH
(TRS LATCHING)
1 2
EXPRESSIO
N
SYNTHESIZER
MINI MINI
SYNTHESIZER
EXPRESSION
SYNTHESIZER
MINI MINI
SYNTHESIZER
6.35MM TRS CABLE
OR
OR
CV Control
(to EF-X2)
+5V Supply
(from EF-X2)
Ground
TIP
RING
SLEEVE
Echo Mute
Reverb Mute
Ground
TIP
RING
SLEEVE
CV OUT (0-5v) CV OUT (0-5v)
