OPTIONS AND ACCESSORIES
If the high-pressure pump is installed less than 1 foot below the waterline or an additional 5micron pre-
filter is added, the installation of an optional boost pump is recommended. The boost pump also extents
pre-filter element life, reduces maintenance and assists in priming the system after pre-filter changes.
Boost pump with intake hose barb, outlet hose barb, 4 feet / 1.2 meter wire reinforced intake hose,
10 feet / 3 meter braided feed hose, 5 micron pre-filter housing, bracket, fittings and cartridge (all
assembled).
5 Micron Pre-filter Housing (1 filter housing, 1 pre-filter cartridge, 1 bracket, 1 3/4” NPT nipple)
An additional 5 micron pre-filter is only recommended in connection with the optional boost pump.
Note: The 5micron filter must be installed as a second filter in flow direction
Maintenance Kit
10 Pre-filters, 5 and/or 20 microns
1 Spare sea strainer screen
2 Active carbon filters (fresh water flush)
1ltr. High pressure pump oil
Extended Maintenance Kit
2 Motor brushes
1 Acid cleaning compound
1 Alkaline cleaning compound
2 Storage compounds (Biocide)
1 Complete spare seal and O ring kit (except high pressure pump)
Fresh water flush kit for installation with boost
pump (filter housing, charcoal cartridge,
stainless steel bracket, 8 screws, shut off valve,
2 x 1/2” hose barb connectors, 1/2” tee, 10ft
1/2” braided hose, 5 x 1/2” hose clamps)
Fresh water flush kit for installation without
boost pump (filter housing, charcoal cartridge,
stainless steel bracket, 8 screws, shut off valve,
2 x 5/8” hose barb connectors, 5/8” tee, 10ft
5/8” braided hose, 5 x 5/8” hose clamps)
Low pressure gauge
The low pressure gauge indicates when the pre-filters have to be
changed. Select pressure range according to freshwater pressure.
