6 5 INCH CHIPPER/SHREDDER
ASSEMBLY
6. Remove driveline pieces (for ease of cutting) and cut
ONLY the outer and inner plastic tubes.
7. After cutting plastic tubes, measure 1‑9/16" (40 mm)
from the ends of both newly cut plastic tubes.
8. Mark the inner steel shafts and cut both shafts at
1‑9/16" (40 mm) as shown in the photos.
2.3 CONNECT CONTROL BOX WIRES
TO TRACTOR
There are two electrical wires (red and white) that come
wrapped around the three-point PTO connector.
● Connect the red wire to a 12-volt power source, such
as the alternator or the battery.
● Ground the white wire (connect to negative post on
the battery or another point).
1-1/4" from Shield
Inner
Tube
Yoke
Shield
1-1/4" from Shield
Outer
Tube
Yoke
Shield
1-9/16" (40 mm)
Outer
Tube
Steel
Shaft
Steel
Shaft
Inner
Tube
9. File both shaft ends to remove sharp edges and slide
the driveline pieces back together.
10. When you have conrmed that the driveline is the
correct length for your tractor, connect the driveline to
the chipper rotor.
11. Connect the opposite end of the PTO shaft to the
tractor.
